Construction part of "Xi'an Luminous Road Studs Zebra Crossing"

Date:2022-08-15
Coring:
This is the most critical part of the entire Road Studs project, and everything is in vain if it is not installed properly. First determine the installation position of the Road Studs, and use a white pen to mark the point 5 cm away from the top of the zebra crossing in the direction of traffic. Use a professional floor coring machine to take cores. The hand-held coring machine is easy to shake, resulting in position deviation. In the lifting position, make a ruler position according to the Road Studs depth of 6 CM to avoid Road Studs drilling too deep and shallow, drilling too deep, Road Studs Studs sink into the ground, light cannot be emitted, and if the drilling is too shallow, Road Studs will protrude from the ground plane, aggravating the impact of vehicles on it, and shortening the life of Road Studs.

Road Studs Installation:
After the grooving and drilling are completed, the installation can be continued after the holes are dried with a musket. If there is water, there will be a problem that the adhesive does not bond with the Road Studs and the road surface.
Put each Road Studs into the hole to test the depth of the hole. If it is too deep, use asphalt stones to level it. If it is too shallow, adjust it with an electric hammer. To ensure that the depth of the holes is just right, the top of the product only protrudes from the road surface by 6 mm.
Connect the Road Studs to each other, pass through a PVC pipe with an inner diameter greater than 0.8cm, and use an electric iron to weld the joints firmly.
Road Studs Adhesive:
The epoxy resin provided by Yuanda Ming is 1:1 ratio, and 20-30% cement is added to ensure that the circumference of each hole and the bottom surface are evenly coated, put in the Road Studs and adjust the direction of the light.
After testing the complete Road Studs for normal operation, the road surface restoration can be carried out.
