LED Solar Traffic Signs, tunnel traffic safety indicator; The types of tunnel electro-optical signboards produced by Henan Ruichen Traffic Equipment Co, Ltd. mainly include: emergency parking zone sign, vehicle type cross hole sign, pedestrian cross hole sign, fire protection sign, emergency telephone sign and evacuation indication sign.
Solar Traffic Signals product specifications and technical parameters for emergency stop
1. Model: R1-1
2. Size: 500 * 800mm
3. Power: ≤ 20W
4. Input voltage: 220V
5. Output voltage: 12V
6. Luminous surface: double-sided
7. Visual distance: ≥ 500m
8. Operating temperature: - 40 -+80 ℃
9. Shell material: aluminum profile+light guide plate
Product specifications and technical parameters of vehicle type crosswalk and pedestrian crosswalk signs
1. Model: TP-SD-CX
Pedestrian crossing TP-SD-RX
2. Size: 500 * 800mm
3. Power: ≤ 20W
4. Input voltage: 220V
5. Output voltage: 12V
6. Luminous surface: double-sided
7. Visual distance: ≥ 500m
8. Operating temperature: - 40 -+80 ℃
9. Shell material: aluminum profile+light guide plate
Product specifications and technical parameters of fire protection signs and emergency telephone signs
1. Model: Fire fighting sign TP-SD-XF
Emergency telephone sign TP-SD-DH
2. Size: 250 * 400mm
3. Power: ≤ 10W
4. Input voltage: 220V
5. Output voltage: 12V
6. Luminous surface: double-sided
7. Visual distance: ≥ 500m
8. Operating temperature: - 40 -+80 ℃
9. Shell material: aluminum profile+light guide plate
Evacuation indicator product specifications and technical parameters
1. Model: TP-SD-SS
2. Size: 250 * 400mm
250*750mm
3. Power: ≤ 15W
4. Input voltage: 220V
5. Output voltage: 12V
6. Luminous surface: single side
7. Visual distance: ≥ 500m
8. Operating temperature: - 40 -+80 ℃
9. Shell material: aluminum profile+light guide plate
Contact: Ms. Xue
Tel.:+86 1523861623
LED Solar Traffic Signs are mainly used to indicate tunnel safety in tunnels. It is a kind of luminous sign with certain figures and symbols that can be clearly identified when the light is dark. It can clearly indicate vehicles and pedestrians when the tunnel is dark, and it meets the design standards in the People's Republic of China transport industry standard JT/T820-2011 Luminous Guidance Facilities for Highway Tunnels. Products can be customized according to requirements.
