Tunnel Active Road Studs Product Description:
Main components: shell, LED, constant current circuit, wire, packaging resin, etc.
Model: 2000-1S Single-sided LED with 6 LEDs 2001-1D Double-sided 12 LEDs
Shell material: engineering plastics
Specifications: 40*180MM
Weight: 50g
LED color: white, yellow. You can also choose red, blue, green and other colors according to the actual situation
Power Consumption: White: 0.6VA (25mA) Yellow: 0.3VA (12mA)
LED average luminous intensity: white: 20cd/, yellow: 22cd
Lifespan: 80000h
LED opening angle: ±30°
Allowable working voltage: 24V DC
Protection class: IP67
Encapsulation: epoxy resin
Connection: 0.5--1.0m soft wire, T-type connection or plug-in connection with heat shrinkable sleeve
Tunnel Active Road Studs product technical parameters:
Main components: paint control box, switching power supply, control circuit, etc.
Power supply system: input AC 220V, output 24V
Main fuse color wire: 6A
Protection mode: short circuit, overload, overvoltage, over temperature
Breaker switch: the current residual current is 30mA (main circuit power supply)
Safety certification: CE
Controller protection level: IP68
Transformer protection grade: IP65
The total weight of the controller including the transformer: about 2.0kg
Output voltage: 24V DC
The amount of branch lines that can be output: 2 (one output line on both sides)
The maximum load current of the lines at both ends: 2.5A
Nominal power: 120VA
Installation: in an existing distribution box or in a separate protection box
Control function: always on or flashing. Advanced function selection: adjustable pulse strobe
Control mode: local dial switch, available for remote PLC control, RS-232 and RS-485
Fault detection: open circuit, overload detection
Fault output: 2 independent fault output points, which can be used for remote detection
Overload protection: automatic protection for each line greater than 2.8A
