Solar Road Studs, Solar Solar Road Studs, China Intelligent Transportation Solar Road Studs Direct Selling Manufacturer——Henan Ruichen Traffic Equipment Co, Ltd. Ruichen is a high-tech enterprise specializing in R&D, design, production and sales of products in the transportation field, and providing customers with excellent solutions and high-quality services.
The company continues to innovate around the needs of customers, cooperates with partners openly, and builds a comprehensive solution in the fields of traffic safety, intelligent transportation, road lighting, etc., and strives to reduce traffic safety accidents and create the best social, economic and environmental benefits. . Currently Ruichen's products and solutions have been used in more than 50 countries.
Ruichen Solar Solar Road Studs is a traffic controller specially designed for solar power supply systems. One host controls multiple extensions, uses wireless communication to coordinate work, has multi-time and multi-program control methods, and uses LCD screen display, easy to master and use. The structure is simple, the installation is convenient, and there is no need to break the ground to lay cables, and only need to install a signal machine at each intersection to realize the traffic control of the entire intersection.
Product parameters:
Shell material: metal shell.
Dimensions: 200*180*40mm.
Input voltage: DC12V±20%.
Output current: 5A per channel, total current ≤20A.
Static power consumption: <0.7W.
Output ports: 13 channels, 3 sets of red, yellow and green signal lights and 2 sets of red and green pedestrian lights.
Period: 12 periods, any scheme can be called.
Scheme: 18 schemes, including yellow flash, all red, and light off.
Phase time: 0~99 seconds can be set.
Strobe setting: yellow flashing, pedestrian green light flashing 0~99 seconds, motor vehicle green light flashing 0~99 seconds
Brightness dimming: 100%, 75%, 50%, 30%, automatic (100% during the day, 50% at night)
Wireless frequency: 433MHz or 2.4GHz.
Effective distance: >200m.
Working temperature: -35℃ ~ 75℃
Working humidity: ≤95%
Executive standard: refer to the relevant regulations of GB25280-2010
Working temperature: -35℃ ~ 75℃
Working humidity: ≤95%
Executive standard: in line with the relevant provisions of GB25280-2010
