1. Identify the system voltage
%6; The system voltage of
Solar Traffic Light is directly determined by the light source. If the light source is 12V, the whole system is a 12V system, and if the light source is 24V, the whole system is 24V. Usually the outer packaging of the light source will indicate the voltage of the light source. If there is no label on the package, please contact us immediately.
2.
Solar Traffic Light cable wire cutting, stripping and wiring
%6; Distinguish panel line and light source line
R26; battery board wire is black sheathed wire
R26; light source wire is red sheath wire
%6; line cropping
Solar Traffic Light solar panel cable length = pole height + 1M
Light source cable length = light source height + arm length
3.
Solar Traffic Light stripping
%6; Strip the cables of the light source, battery and solar panel respectively.
%6;
Solar Traffic Light wrap the positive "+" and negative "-" of the battery and solar panel cables with insulating tape to prevent short circuits
4. Wiring
%6; Connect the light source cable to the light source and fasten it with insulating tape
